ZEISS 3D CNC CMM - CONTURA- SIZE 900 X 1200 X 800 mm
List of Measuring & Testing Equiments
- Vernier Caliper (0-300mm)
- Vernier Caliper (0-600mm)
- Vernier Caliper (0-1000mm)
- Dial Vernier Caliper (0-300mm)
- Inside Vernier Caliper (0-150mm)
- Depth Vernier (0-300mm)
- Micrometer(0-25mm)
- Micrometer(25-50mm)
- Micrometer(50-75mm)
- Micrometer(75-100mm)
- Micrometer(100-200mm)
- Micrometer(150-300mm)
- Micrometer(300-400mm)
- Micrometer(400-500mm)
- Hardness Tester
- Surface Table (630 X 630 Mm)
- Surface Table (1000 X 630 Mm)
- Digital Vernier Caliper (0-300mm)
- Depth Micrometer (0-25mm)
- Plunger Dial(0.01mm)
- Plunger Dial(0.001mm)
- Digital Plunger Dial(0.001mm)
- Lever Dial Gauge(0.01mm)
- Bore Dial Gauge(10-18.5mm)
- Bore Dial Gauge(35-60mm)
- Bore Dial Gauge(18-35mm)
- Bore Dial Gauge(50-150mm)
- Bore Dial Gauge(160-250mm)
- Digital Height Gauge(0-600mm)
- Height Gauge(0-600mm)
- Pistrol Caliper(0.100mm)
What We Offer
All grades of Steel, Alloy Steel castings & Iron Castings
Melting Unit
- The total production capacity is 150 tones per month & presently we are making 125 tones in this unit. This capacity is being increased to 250 tones p.m
- Electric induction furnace of 300kg and 500kg
Moulding
- Shell Molding facility. (Two production lines having automatic Core Shooters molding machines & shell closing machines.)
- Pneumatic Molding Machine 2 nos.
- Hand Molding in green Sand, CO2 and No-Bake Sand. Induction furnace is being added to double the melting capacity to take care of future additional load
Pattern Shop
- Having In house pattern Shop, also sourcing work from outside
Finishing
- Shot Blasting Machine 48” Table Type, Double Door.
- Pedestal Grinders, Flexible shaft Grinders, Pneumatic chippers, Grinders of Various Sizes and Swing Grinder.
Heat Treatment
- Electric Furnace 1.5MT, capacity with Modernized temperature controllers. This capacity is being increased to 250 tones p.m
- Additional capacity of 2 MT is added.
- Parameters with graphic printing automatic control system.
- Water Quenching/ Air Quenching facilities available.
Quality Equipment’s
- Spectrometer (Germany Spectromax make) for complete metal analysis.
- Hardness tester for testing smaller castings.
- Ultrasonic testing Equipment to check blow holes.
- Magnetic particle inspection equipment for testing surface cracks on castings.
- Microscope to check the micro structure of casting.
- UTM machine for Tensile, Elongation Test and Yield Test.
